BS EN 12983-1 Scratch Resistance Tester For Test Scratch Resistance Of Cooker Coating
Products Description
BS EN 12983-1 Scratch Resistance Tester For Used To Test The Scratch Resistance Of Cookers
Applied standards:
BS EN 12983-1 clause 8.4.2, 8.4.3 and Appendix K.
Purpose, principle and structure of apparatus:
The device uses the pencil nib to compare the scratch resistance of the coating; Apply 4&8N pressure to the pencil; Insert the pen core into the hole where the hole is 45°, then the pencil nib completely touches the bottom coating of the pot, and then draw a 2~5cm line on the coating; Judge the effect by the lines drawn.
Main specifications:
1. Power supply: AC220V, 50HZ
2. Test station: 1
3. Drive mode: electric + eccentric wheel mechanism
4. Test speed: 0-10 times/min, adjustable
5. Scratch length: 20~50mm, adjustable,default 25mm
6. Scratch angle:45 °
7. Test mass: one of each 4N, 8N;
8. Pencil: one of each HB,2H,3H,4H,5H.
9. Overall dimension:WDH=900×500×700mm, Maximum allowable sample Ф400mm.
10. Heating platform DB-2EFS:
5 Power on the equipment, select the test according to your requirements.
Ambient temperature test: Test at room temperature, select 8N load;
High temperature test: Turn on the power of the heating platform to start heating, set the temperature of the heating platform (standard requirement is 200℃), and select 4N load.
Note: During the high temperature test, when the temperature display of the heating platform reaches the set value, press the start button to start scraping, and observe whether the speedometer under the panel is the speed required for the test. If not, you can adjust the speed controller on the panel.
6 Set test times.
7 After the test is completed, check whether the cookware meets the requirements according to the standard.
Maintenance:
1 Before working, please check whether the fasteners are loose, and make sure that the loose fasteners are locked.
2 Do not touch the surface of the heating platform when heating to prevent burns.
3 Please remove the weight when it is not working.
4 Please cut off the power when not working.
Graphite heating plate
Product model
DB-XEFS
DB-1EFS
DB-2EFS
DB-3EFS
Power supply/power
AC220V/50Hz
The whole machine power
1.6KW
2KW
3KW
4KW
Display mode
LCD display
Operating temperature
50-420℃
Temperature control precision of instrument
±1℃
Temperature uniformity
3%
Heat the size
300*200mm
400*280mm
450*350mm
600*400mm
The plate material
graphite
The plate thickness
12mm
bearing
5kg
The net weight
9kg
13kg
18kg
30kg
Product size
30*35*20cm
40*43*20cm
45*50*20cm
60*55*20cm
