Clause 18 Microwave Oven Door Endurance Test Equipment IEC 60335-2-25
Products Description
IEC 60335-2-25 Clause 18 Microwave Oven Door Endurance Test Equipment
Brief Introduction:
It is conforms the standard of IEC60335-2-25:2006 clause 18.This apparatus is a special tester which is used to test the abrasion resistance of the microwave oven door system, including the structure of the hinge, microwave seal and other related parts during use.
The mechanical arm is driven by the motor which drives the vacuum suction cup to suck the microwave oven door to open and close at a certain speed and angle to verify the reliability of the door system including hinges, microwave oven seals and other related components.
Technical Parameters:
Test station
Single station
Control method
PLC intelligent control,7-inch humanized touch interface operation
Drive
Stepper motor drive
Sample clamping method
Vacuum suction cup, pneumatic
Opening/Closing speed
0-360°/s,adjustable
Interval time of opening/closing
0-99.9s,adjustable
Test frequency
6 times/min, a cycle is formed by the door opening/closing process and the pause time
The angle of opening/closing
0-135°,adjustable
Test times
0-999999 time,adjustable
Load currency
Voltage 0-250V, adjustable, current can be displayed. It is equipped with 10A power socket which can work with samples below 2000W
Microwave oven door interlock switch button, pneumatic
Microwave oven door interlock switch button, pneumatic
