IEC 60335-2 Microwave Oven Testing φ190mm Cylindrical Borosilicate Glass Vessel
Products Description
IEC 60335 Microwave Oven Testing φ190mm Cylindrical Borosilicate Glass Vessel
Product Overview:
The Ф190mm Cylindrical Borosilicate Glass Vessels conforms to the standard requirement of IEC 60335-2-25 clause 3 and 32.
Technical Parameters:
Customized Service:
KingPo can offer many vessels made by borosilicate glass or other materials as per different IEC standard requirements, also can offer customized vessels as per client's specific testing requirements.
Test Procedures and Operation:
Please refer to the relevant standards.
Take IEC 60335-2-25 clause 3 as an example:
Compliance for the microwave normal operation is checked by the following test. Operation of the appliance with 1000g±50g of potable water at an initial temperature of 20°C±2°C in a cylindrical borosilicate glass vessel having a maximum thickness of 3mm and an outside diameter of approximately 190mm. The vessel is placed on the centre of the shelf.
Notice:
1. Please do not damage the appliance shape (such as scratching, bending, etc.).
2. Wear insulation gloves when moving the vessel from microwave oven to avoid high temperature burns.
3. Handle with care, to avoid broken of the vessel.
The φ190mm vessel is an auxiliary tool to process the normal operation testing of microwave ovens.
Applied standard
IEC 60335-2-25 clause 3
Specifications
Φ190mm Vessel
Material
Borosilicate glass
Shape
Cylindrical
Diameter
Bottom diameter: 190mm
Height
90mm
Capacity
2000ml
Container wall thickness
Between 2mm-3mm
