IEC 61851-1 Cable Anchorage Pull Force And Torque Test Apparatus For EV Charging Station Testing
Products Description
IEC 61851-1 Cable Anchorage Pull Force And Torque Test Apparatus For EV Charging Station Testing
Product information:
It is designed and manufactured according to IEC 61851-1:2017 clause 11.6.
Power supply: AC220V±10%/50-60Hz, 1KW; working temperature 0-40℃, humidity 30%-90%;
Dimensions: about W1600*D600*H1450mm; weight: about 180kg
Technical parameters:
Sample scope, purpose, principle, structure and use environment
Samples and restrictions
Electric vehicle charging station
Test purpose
Used to test the ability of electric vehicle charging station connection cable accessories to withstand specified tension and torque
Test Principle
The pulling force is realized by using a motor to drive an eccentric wheel mechanism or a screw mechanism. The motor speed is adjustable to ensure that the pulling force is applied accurately each time. The torque is realized by using a motor, a tray, a weight and a time relay.
Structure and characteristics
The weight is used to apply tension, and the weight and the torque arm realize torque. The PLC is used to control the number of tensions and the torque test time. When the number of tests or the test time is reached, the equipment automatically stops. After the test, the maximum allowable displacement of the charging gun connector cable shall not exceed the standard requirement value.
Usage Environment
Test content
Supply plug and/or vehicle plug cable of EV charging station tension test and torque test
Equipment structure schematic diagram
Refer Schematic
Control operation mode
PLC automatic control, touch screen operation
Drive mode
Electric
Pull apply
Meet 160N, 200N, 240N, 250N, 500N specifications, realized by superposition of weights
Torque apply
Meet 0.6N·m, 0.7N·m, 1.4N·m, 2.7N·m, 5.4N·m, 11.0N·m, 16.3N·m specifications,realized by superposition of weights
Torque wheel
R100mm(Ф200mm) ±0.5mm
Tensile frequency
1 time/s, the actual pull time is detected by electrical signal
Pull cycles
1-999999 cycles, can be preset, default is 100±1 cycles
Torque application time
0-99H59M59S,can be preset
Power failure protection
With power-off data storage memory function
Fixture
Universal clamp, one set
Weight matching selection table
