Wire Harness Thermal Cycle Temperature Rise Test Bench Touch Screen
Products Description
Wire Harness Thermal Cycle Temperature Rise Test Bench Touch Screen
This product complies with the following standards:
CURRENT and temperature increase test method for ELECTRICAL connectors UL310, UL498, UL817, UL941, UL1059, IEC60309, IEC60998, IEC60669, IEC61058, IEC60439, EIA-364-70 and other electrical accessories The relevant standards were developed. It can be used to assess the surface heating of electrical accessories when the load current is connected, and whether the temperature rise of the electrode meets the standard requirements.
Product overview:
Adopt high precision 200A power supply.
Output constant adjustable test current: DC3 ~ 200A two gear continuous optional.
Working mode: continuous mode, on - off mode, automatic temperature control mode.
Measuring range: 0 ~ 260℃ accuracy 0.3% reading +1℃; Resolution: 0.1℃.
Temperature probe can be charged AC300V test, will not damage the instrument.
Specifications of test chamber: width 800mm× depth 800mm× height 1800mm, weight about 150kg, with mobile casters.
Temperature data recording: automatically completed by the computer.
Accessories list:
No.
Product Name
Brand
Unit
Number
1
Custom cabinets
KingPo
unit
1
2
Integrated touch screen LCD display Industrial computer
custom
unit
1
3
Operating system + program control software
custom
unit
1
4
Multichannel temperature rise tester
Chinese famous brand
unit
1
5
Dc power supply
Chinese famous brand
unit
1
6
Program controlled current source
custom
unit
1
7
Temperature rise test fixture
custom
set
1
8
Voltage-current collector
custom
set
1
9
Programmed time controller
custom
set
1
10
Voltage switch and electrical hardware accessories
Chinese famous brand
set
1
Computer test software can be configured, Excel report can be exported:
