Clause 21.101 1.5kN Crushing Resistance Test Equipment IEC 60335-2-2
Products Description
IEC 60335-2-2 Vacuum Cleaners Current-Carrying Hoses Crushing Resistance Testing Equipment
Standards & Clauses:
This current-carrying hoses crushing resistance test equipment meets the requirements of IEC 60312-2-2 clause 21.101.
It is used to assess the vacuum cleaners or water-suction cleaning appliances' current-carrying hoses should be resistant to crushing.
Test Procudures (Extracted from IEC 60035-2-2:2019 clause 21.101):
The hose is placed between two aprallel steel plates each having a length of 100mm, a width of 50mm and the edges of the longer sides rounded with a radius of 1mm. The axis of the hose is positioned at right angles to the longer sides of the plates. The plates are placed at a distance of approximately 350mm from one end of the hose.
The steel plates are pressed together at a rate of 50mm/min± 5mm/mim until the applied force is 1.5kN. The force is them re;leased and the electric strength test is carried out between the conductors connected together and the saline solution.
Technical Parameters:
0 to 999999 times can be preset
Input Power
Match client's local power supply requirements
Control Method
Micro-computer, LCD touch screen
Station
One (can be customized)
Required test plate
Length of 100mm, a width of 50mm and the edges of the longer sides rounded with a radius of 1mm
Crushing method
Stepper motor pressure
Crushing force range
1 ~ 2000N using high-precision pressure sensor
Crushing rate
50mm/min± 5mm/mim
Crushing distance
350mm
Testing times
Clamping mechanism
The special fixed fixture can be fastened and clamped easily and conveniently. (The actual fixture is subject to the standard sample provided by the customer)
