IEC 60335-2-9 Figure 105 Probe For Measuring Surface Temperatures
Products Description
IEC 60335-2-9 Figure 105 Probe for Measuring Surface Temperatures
Product overview:
This surface temperature measuring test probe conforms to the IEC 60335-2-9:2019 clause 11.3 Figure 105, IEC 60335-2-11 Clause 11.3 Figure 101, IEC60335-2-6-2002 clause 11.101 figure 104, etc. It is mainly used to measure the temperature rise on the front surface of the easily accessible parts of electrical appliances such as drum-type dryer, upright electric cooker, cooking bench and oven.
Technical Characteristics:
How to measure the surface temperature with this test probe? (Extracted from IEC 60335-2-9:2019 clause 11.3)
For flat surfaces, temperature rises are measured using the probe of Figure 105. The probe is applied with a force of 4N±1N to the surface in such a way that the best possible contact between the probe and the surface is ensured.
Applied standards
IEC 60335-2-9 clause 11.3 Figure 105, IEC 60335-2-11 clause 11.3 Figure 101, IEC60335-2-6 clause 11.101 figure 104, etc.
Thermocouple wires
0.3mm diameter to IEC 60584-1 Type K (chrome alumel)
Handle arrangement permitting a contact force
4±1 N
Polycarbonate tube
Inside diameter 3mm, outside diameter 5mm
Tinned copper disc
5mm diameter, 0.5mm thick
