IEC62196-1 Clause 7.11 EV Connector And Plug Breaking Capacity Test Equipment
Products Description
IEC62196-1 Clause 7.11 EV Connector And Plug Breaking Capacity Test Equipment
Product Information For EV Connector And Plug Breaking Capacity Test Equipment:
The Vehicle Connector and Plug Breaking Capacity test machine conforms to the standard requirements of IEC60309-1 clause 20 and clause 21, IEC62196-1 clause 7.11 and clause 7.12 and etc.
It is used to verify whether electrical accessories such as electric vehicle charging interfaces, industrial plugs, socket-outlets and couplers can withstand the mechanical, electrical and thermal stresses that occurred during normal operation without excessive wear or other harmful effects.
The servo motor drives the mechanism to make the test samples repeat insertion and withdrawal actions. An external load can be used for the breaking capacity test. The power on / off time, test speed, stroke, and angle can all be preset on the touch screen.
Technical Parameters For EV Connector And Plug Breaking Capacity Test Equipment:
Appliance coupler/charging interface breaking capacity test
Appliance coupler / charging interface normal operating life test
Test station
Single
Control method
PLC intelligent integrated control, with color humanized touch screen
Drive mode
Servo motor drive
Sample clamping method
Mechanical clamping, the position of clamping point can be adjustable along the 3-axis fixture
Linear stroke
0-100mm, can be preset (the spacing between test plug and test socket≥ 50mm)
Conduction time
0-99.9s, can be preset (electrical contact should be maintained no more than 4s, no less than 2s)
Speed of Insertion and Separation
0-0.85m/s can be preset, default (0.8±0.1) m/s
Test frequency
0-10 cycles/min, can be preset (3.75cycles/min=7.5 stoke/min)
Test cycles
0~999999 cycles, can be preset
Load power
External, providing standard required voltage, current and power factor, the load cabinet is optional
Optional load cabinet
Note: only with AC load cabinet, 0-70A, voltage 0-300V
Test contents
Detection function
An open circuit alarm can be realized during testing under load, and the cycles can be recorded real in time.
Safety protection
Ground protection, short circuit protection
Power Supply
Single phase AC220V±10%, 50/60Hz, 10A
