IEC 61851-1 20J Impact Force Mechanical Impact Device For Impact Test
Products Description
IEC 61851-1 20J Impact Force Mechanical Impact Device For Impact Test
Product information:
This mechanical strength impact test equipment complied to IEC 61851-1 2017 clause 12.11 standards.
1. Main purpose: This device is composed of two kinds of impact test apparatuses, and two kinds of mechanical strength test methods can be used to perform impact test on EVSE shell.
2. Installation sample: installation of a single sample is less than 1min.
3. Applicable sample size:
4. The impact energy is formed by releasing the pendulum through the electromagnet; and it has automatic electric brake to prevent secondary impact;
5. The equipment is controlled by PLC, controlled by touch screen and remote control, and the height of the strike point can be adjusted by electric lift;
6. The adjustment of the striking height and the release of the striking element can be controlled remotely;
7. The sample mounting seat is welded by high-strength steel plate and channel steel, which has the characteristics of high strength and impact resistance. The sample to be tested is fixed with a manual screw rod.
Technical parameters:
Minimum (length × width × height, unit mm): customized according to the sample;
Maximum (length × width × height, unit mm): customized according to the sample;
Control and operation
PLC control, 7-inch color touch screen control, remote control remote control.
Drive mode
Motor + reducer mechanism
Pendulum impact
Impact force
Standard 20J
Pendulum mass accuracy
±1%
Equivalent mass of impact hammer
5kg
Impact hammer form
Spherical impact hammer
Pendulum striking point height adjustment range:
Customized according to the sample
Pedulum arm height adjustment range
200-500mm
Specimen clamping adjustment range
Customized according to the sample
Impact point height adjustment
Electric adjustable
Number of impacts
0-9999 times can be preset
Status indication
LED indicator
Pendulum height (energy) adjustment
Manual adjustment
Pendulum positioning
Electromagnet adsorption
Pendulum release
Wireless remote control or touch screen operation
Impact point height adjustment method
Wireless remote control or touch screen operation
Security
360° all-round safety protection, automatic electric brake to prevent secondary impact
Vertical impact
Impact force
Standard 20J
Installation method
The hammer head is adsorbed by electromagnet, and the conduit is screw-in type
Release method
Button control, electromagnet momentary release
Hammer release
Remote control
Height adjustment method
Remote control
