IEC60529 IPX7 Immersion Test Chamber For Factory Inspection
Products Description
IEC60529 High Quality IPX7 Immersion Test Chamber For Factory Inspection Use
Product information:
Standard:IEC60529 degree of protection provided by enclosures (IP Code) of the IPX7, IEC60884-1, IEC60335-1, IEC60598-1.
Technical Parameters:
Chamber external size
Approximately W 1080* D 1080*H 2300mm (including casters)
Chamber inner size
Length 1000* W 1000* H1800mm
Max. test water depth
1.8m
Observation window
Tempered glass (thickness: 12mm)
Observation window width
200mm
Water level adjustment method
Water inlet / drain valve, manual adjustment
Water level display
Scale (accuracy 1mm)
External chamber material
Stainless steel plates + Aluminum profile frame
Inner chamber material
2.0mm thickness stainless steel
Electric lifting basket
Made of stainless steel, controlled by electric hoist
Control method
Buttons (non-PLC)
Test time
0.01 second-99.99hours can be preset
Immersion depth requirements
The lowest point of enclosure with a height less than 850 mm is located 1000mm below the surface of the water
The highest point of enclosure with a height equal to or greater than 850mm is located 150mm below the surface of the water
Test content
IPX7
Power supply
AC 220V,50Hz, 1KW
Application:It is used for the testing of IPX7. Mainly used to test the product waterproof performance in the soaking environment. Through the test, check whether the product waterproof level meet the requirements, for product design, R&D and factory inspection use.
