42MPa Car Refrigerating Compressor High Pressure Resistance Test Bench Computer Control
Products Description
42MPa Car Refrigerating Compressor High Pressure Resistance Test Bench Computer Control
Standards & Clauses:
IEC60335-2-24:2017 “Household and similar electrical appliances-Safety-Part2-24: Particular requirements for refrigerating appliances, ice-cream appliances and ice-makers, IDT” clause 22.7 and clause 22.103.
Samples and Restrictions:
Compressive appliances using flammable refrigerants and appliances using transcritical refrigeration systems.
Application:
Used for pressure resistance and leakage test of compression appliances.
Test Principle:
The high pressure is output from the booster pump of the system according to the different pressure of the sample, and then the pressure resistance performance of the sample is inspected.
Structure:
It consists of electrical control system, circulation system and pressure control system. The workpiece can be quickly installed manually and controlled.
Use Environment:
Power supply: AC380V±10%/50-60Hz or match client’s local power supply requirements
Air source: 0.5-0.7MPa compressed air
Use place: atmospheric pressure 80 ~ 106kpa; ambient temperature 5 ~ 40 ° C; relative humidity (20 ~ 80) % RH; no vigorous shaking, vibration, electromagnetic interference, dust, explosive and corrosive gas, with good heat dissipation
Technical Parameters:
Test Station
Single station, multi stations can be customized
Electrical Control Method
Computer intelligent control and operation
Test Pressure
1.5-42MPa
Pressure Control Accuracy
+2% of the upper limit, -1% of the lower limit
Test Medium
Clear water
Pressure Control Method
Computer control
Ambient Temperature
Room temperature
Pressurized Flow
2.6L/min
Drive Pressure
0.2-0.8MPa
Drive Flow
0.3-1 Cubic/minute
Time Display
Computer display
Pressure Curve Display
Can be displayed in real time, and zoomed in and out
Print Report
After the test is completed, the test report can be printed, and the test data can be saved.
Test Data Storage
Reports can be saved into excel forms, and the data collected each time can be saved.
Pressure Display Accuracy
0.1MPa
Safety Protection
Power
Leakage protection, overload and short circuit protection
Motor
Overload, short circuit protection
