Vehicle Ferrous Parts Clause 30 IEC 62196-1 Air Saturated Aging Chamber
Products Description
IEC 62196-1 Air Saturated Aging Chamber for Vehicle Ferrous Parts
IEC 62196-1 Vehicle Ferrous Parts Rusting Resistance Air Saturated Aging Testing Chamber
Product information:
This air saturated test chamber is required by IEC 62196-1Ed.4CDV 2020 clause 30. It is used to process further rusting in saturated water vapor for plugs, screws and other metal components after being soaked in ammonium chloride water.
Chamber features:
1. Adopt microcomputer temperature controller. +, M. +. Control LED digital display.
5. Fully automatically control.
Technical parameters:
KingPo can offer various of environmental test chambers with high quality, and also can offer customization service according to different standards and clients' specific requirements.
2. Adopt platinum temperature sensor (PT-100), and temperature is precisely controllable with resolution ability 0.1℃.
3. Water vapor test target can be set and controlled, steam test operation timing can be set and controlled.
4. Inner chamber stainless steel material: SUS#316 full argon welding, and outer chamber: SUS#316 material.
No.:
Name
Specifications
1
Input power
Match client’s local power supply
2
Chamber inner size
W250mm×D200mm×H200mm (can be customized)
3
Test saturated water vapor temperature
(20±5)℃
4
Humidity indication
LCD temperature and humidity meter displays the current ambient temperature and humidity
5
Timer
0.1～999.9s/m/h continuous timing and setting, there will be a buzzer sound when the timer reaches the set value
6
Response time
Up to 99% within ≤1min
7
Chamber material
SUB304 stainless steel
