IEC 62368-1 Annex S Needle Flame Test Method Fire Hazard Testing Apparatus
Products Description
IEC 62368-1 Annex S Needle-flame Test Method Fire Hazard Testing Apparatus
Product Information:
The Needle-flame Test Method Fire Hazard Testing Apparatus is designed and manufactured according to the standard requirements of IEC 62368-1 Annex S, IEC60335-1 clause 30.2, Annex E, etc.
It consists of a Ф0.9mm needle-shaped burner that tilts with the angel of 45°and provide it with butane gas. The fire hazard of the equipment when there is flammule inside the equipment that caused due to the fault condition is assessed by whether the specimen can be ignited or the combustion time and length.
The Needle Flame Tester has PLC control and 7-inch color touch screen, it is suitable for the research, production and quality testing department of lighting equipment, low-voltage apparatus, household appliance, machine tool electric appliance, electrical machine, electric tool, electronic instrument, electrotechnical instrument, electrical connector, electrical and electronical equipment and other components. It is also suitable for insulating material, engineering plastics or other solid combustion material industry.
Technical parameters:
Applied standard
IEC 62368-1
Applied clause
Annex S
Working voltage
AC 220V/50Hz
Control
PLC
Display
7-inch color touch screen
Timing device
9999X0.1S
Combustor
Inner boreφ0.5mm ± 0.1mm, OD ≤φ0.9mm, L ≥ 35mm, stainless steel
Combustion angle
tilt 45° (testing) or vertical (when adjust the height of the flame)
Height of the flame
12±1mm adjustable (with flame height gauge)
Gas category
95% butagas (can use the bottled lighter gas)
Range of temperature test
0~1000℃
Flame warming requirement
From 100°to 700°, time for standard values within 23.5S±1S
Temperature thermocouple
φ0.5 armour nickel-chromium/nickel aluminum wire K-Thermocouple
Work shop
0.5 cube, stainless steel case, black yogin background
Testing process
Test procedure automatic control, independent air draft
Volume size adjustment
Flowmeter adjustment
Equipment size & weight
1100mm* 550mm* 1100mm, 120KGS
