Products
IEC 62368-1 2018 Clause 5.3.2, V.1.5 Figure V.4 Wedge Probe
Products Description
IEC 62368-1:2018 Clause 5.3.2, V.1.5 and Figure V.4 Wedge Probe
Product Information:
The wedge probe conforms to the standard requirement of IEC 62368-1:2018 clause 5.3.2, 8.5.4.3, V.1.5 and figure V.4, IEC 60950-1 Fig NAF.2(S5366)and NAF.3(S5370), BS 60950.1108/260/CD and etc.
It is used to test whether the slot openings can be touched by people. The test samples include information technology equipment.
Technical Parameters:
Part of Dimension:
The thickness of the probe varies linearly, with slope changes at the following points along the probe:
Applied standard
IEC 62368-1
Applied clause
5.3.2, V.1.5 and figure V.4
Probe material
Stainless steel
Applied Specimen
Document/media Shredders
Distance from probe tip, mm
Probe thickness, mm
0
2
12
4
180
24
