Coupler Heating Tester For Evaluating Heat Resistance Performance Testing IEC60320-1
Products Description
Coupler Heating Tester For Evaluating Heat Resistance Performance Testing IEC60320-1
Product information:
Standard:IEC60320-1:2021 clause 18.2 and figure 5, IEC60320-3:2022.
Test purpose: used to evaluate the heat resistance performance of appliance couplers under thermal conditions or extreme heat conditions.
Power supply: AC220V±10%/50-60Hz, working temperature 5-35℃, humidity 30%-90%.
Technical Parameters:
Test station
Single station
Electrical control method
Button control, digital display
Heating method
Electric heating, RT+10~160℃±2℃, can be preset
Test items
C16: 10A heat-resistant appliance input socket: test 10A connector, test temperature 120°±2°;
C16A: 10A heat-resistant appliance input socket: test 10A connector, test temperature 155°±2°;
C22: 16A heat-resistant appliance input socket: test 16A connector, test temperature 155°±2°;
N: 10A heat-resistant appliance output socket: test 10A plug connector, test temperature 120°±2°;
P: 10A heat-resistant appliance output socket: test 10A plug connector, test temperature 155°±2°;
R: 16A heat-resistant appliance output socket: test 16A plug connector, test temperature 155°±2°;
Test time
0-99 hours and 59 minutes can be preset;
Coupler center distance
Arranged uniformly in a circle of Φ175
Standard gauge
The standard 10A heat-resistant, 10A extreme heat-resistant and 16A extreme heat-resistant appliance input sockets and appliance output sockets are heating gauges, 3 each of C16, C16A, C22, N, P and R, 18pcs in total.
