IEC 60312-1 Vacuum Cleaner Threshold Or Hitting Doorpost Impact Test Equipment
Products Description
IEC 60312-1 Vacuum Cleaner Threshold Or Hitting Doorpost Impact Test Equipment
Standards For Vacuum Cleaner Threshold Or Hitting Doorpost Impact Test Equipment:
This bump testing equipment meets the requirements of IEC 60312-1 clause 6.7, figure 14 and 15.
It is used to assess the vacuum cleaner's ability to resist bump when passing through a threshold or hitting a doorpost. A total of 500 cycle tests are performed to evaluate the running life and bump resistance of the vacuum cleaner. At the same time, the durability of the vacuum cleaner's current-carrying hose was also tested. It is a high-performance quality inspection tool for vacuum cleaners.
Technical Parameters For Vacuum Cleaner Threshold Or Hitting Doorpost Impact Test Equipment:
Equipment Features For Vacuum Cleaner Threshold Or Hitting Doorpost Impact Test Equipment:
The test threshold and doorpost are designed according to the standard drawing requirements. There is a threshold barrier at 1M distance to the vacumm cleaner on the running table, and the impact doorpost is set at 2M. The servo traction motor + wear-resistant elastic rubber belt drive system is adopted. The machine is equipped with a vacuum cleaner dust tube fixture. The clamp fixing mechanism and the running guide system are made of low-friction stainless steel, which is durable and smooth. The control system adopts the operation mode of Mitsubishi PLC+Taiwan WEINVIEW touch screen. The test equipment can control the power on and off of the vacuum cleaner, and the power on and off time is adjustable. The walking speed and the number of tests can be set. When the test is completed, it will automatically stop and give an alarm. Even if the power is cut off, the current test times will be retained, and the remaining tests will continue to be completed after the call.
Input Power
Match client's local power supply requirements
Control Method
PLC control, touch screen operation
Station
One (can be customized)
Test bench size
2500×800×1500mm
Threshold distance
1000mm
Doorpost distance
2000mm
Running speed
550mm/s, the relative travel distance of the vacuum cleaner is greater than 0.5m, and the travel speed is greater than 0.5m/s adjustable
Counting range
0-99999
Drive mechanism
The motor pulley drive mode, which has the characteristics of stable operation and long service life
Clamping mechanism
The special fixed fixture can be fastened and clamped easily and conveniently. (The actual fixture is subject to the standard sample provided by the customer)
