IEC 60320-1 Single station Coupler Pulling Test Equipment Connector Test For Household

Standards For Coupler Pulling Test Apparatus:

IEC60320-1:2021 "Appliances couplers for household and similar general purposes- Part1:General requirements" clause 23.3 and figure 19.

Test principle For Coupler Pulling Test Apparatus:

Insert the connector into the device inlet corresponding to the type of connector to be tested and in accordance with the relevant standard table, and apply a lateral force to it using a spring force mechanism.

Technical parameters For Coupler Pulling Test Apparatus:

Test station	Single station
Flexible cable bending height	40±2 mm,adjustable
Power supply	AC 220V, ±50Hz
Working temperature	5-35℃
Humidity	30%-90%
Pull force range	0-100N
Pulling method	50 times in one direction and then 50 times in the opposite direction
Cable selection and corresponding pull value table
Appliance input socket	Optional gauge according to requirements
