IEC 60335-1 Electrical Clearance Measuring Gauge Creepage Distance Test Cards
Products Description
IEC 60335-1 Electrical Clearance Measuring Gauge Creepage Distance Test Cards
Standards & Clauses:
Article 27 of GB2099.1-2008 "Plugs and Sockets for Household and Similar Purposes Part 1: General Requirements"
Samples and Restrictions:
This Electrical Clearance Measuring Gauge Creepage Distance Test Cards suitable for measuring the distance between two conductive parts or between a conductive part and the accessible surface of the appliance along the surface of the insulating material
The gauges are used to determine the shortest path between two conductive parts, or between a conductive part and the bounding surface of the equipment, measured along the surface of the insulation, with specifications made according to the requirements.
Technical Parameters:
The set of creepage distance gauges are integrated with 30 pieces of creepage distance gauges:
1.0mm/1.05mm/1.1mm/1.2mm/1.25mm/1.3mm/1.4mm/1.5mm/1.6mm/1.7mm/1.8mm/1.9mm/2.0mm/2.1mm /2.2mm /2.4mm
/2.5mm/2.8mm/3.2mm/3.6mm/4.0mm/4.2mm/4.5mm/5.0mm/5.6mm/6.3mm/7.1mm/8.0mm/9.0mm/10.0mm
Material: Stainless steel
Article 23 of GB16915.1-2014 "Switches for household and similar fixed electrical installations-Part 1: General requirements"
IEC60884-1: 2006 "Plugs and socket-outlets for household and similar purposes- Part1: General requirements" clause 27
IEC60669-1:2007 "Switches for household and similar fixed-electrical installations-Part1: General requirements" clause 23
Sample scope, purpose, principle, structure and use environment
Sample range
Electric appliance conductive parts
Test purpose
Suitable for measuring the distance between two conductive parts or between a conductive part and the accessible surface of the appliance along the surface of the insulating material
Test principle
Stainless steel claw type to verify the creepage distance between conductive parts
Performance
Size
1.0,1.05,1.1,1.2,1.25,1.3,1.4,1.5,1.6,1.7,1.8,1.9,2.0,2.1,2.2,2.4,2.5,2.8,3.2,3.6,4.0,4.2,4.5,5.0,5.6,6.3,7.1,8.0,9.0,10mm
Specification
One set for straight and curved
Material
Stainless steel plate
