IEC 60335 Electrical Insulation Performance Overflow Test Apparatus PLC Control
Products Description
IEC 60335 Electrical Insulation Performance Overflow Test Apparatus PLC Control
Product overview:
The equipment conforms to IEC 60335-1:2004(Ed 4.1) requirements and IEC60335-2-15:2005, IEC 60335-2-14:2006 test requirements.
Technical parameters:
It can be in 1min with 1% sodium chloride solution (container capacity of 15%, or 0.25L solution with the same concentration, the two take more) evenly into the container of the test appliance.
Use: The structure of the product in normal operation will accidentally splash water outside the container, or the water in the container is too full, when energized, the water will boil over and so on. This equipment is used to test the liquid heater for moisture resistance test, the sample can ensure that the overflow of water does not affect their electrical insulation performance.
Control Mode
PLC controller control, man-machine interface for operation
Driven Mode
Stepper motor driven, stainless steel piston water injection cylinder
Tilt angle
0~20 degrees adjustable
Flow control range
250ml-900ml
Water injection speed
250ml-900ml per minute can be set
Funnel specifications
Pipe diameter 8mm, length 30mm funnel
Test point alignment
Laser alignment
Adjustable height
Maximum 400 mm
Sample table placement size
350x350mm
