IEC 60529 IPX5 Spray Nozzle With Digital Flow Meter Ф6.3mm 12.5L/Min
Products Description
IEC 60529 IPX5 Spray Nozzle with Digital Flow Meter
Product information:
The jet nozzle is used to verify the protective performance of the enclosure for electronic and electrical products, automobiles, motorcycle parts, household appliances, seals and lamps under water jets at degree IPX5.
It ensures that the water spray speed reaches the standard required value by controlling the water supply flow, the enclosure is sprayed from all practicable directions with a stream of water from the standard test nozzles as shown in IEC 60529 figure 6.
Feature:
The IPX 5 hose nozzle set consists of a jet handle that is equipped with a digital flow mater and a pressure gauge.
– Interchangeable nozzles that assemble easily to the gun.
– Stainless steel joint, easy to butt fiber hose.
Technical parameters:
IP Code
IPX5
Nozzle Internal Diameter
Ф6.3mm
Delivery Rate per Standard requirements
12.5±0.625L/min
Distance from Nozzle to Enclosure Surface
2.5~3m
Core of the Substantial Stream
Circle of approximately 40 mm diameter at 2.5 m distance from nozzle
Test Duration
Likely 1min/m² (minimum: 3 min)
Pressure Gauge
0~0.25MPa
Digital flow meter
8L/min ~120L/min
