IEC 60669-1 Clause 17 Test Set Up Device For Temperature Rise Test Switches
Products Description
IEC 60669-1 Clause 17 Test Set Up For Temperature Rise Test
Product information:
The device is made and manufactured according to the related standard requirement of temperature rising, such as IEC 60669-1 Clause 17, IEC 60884-1 clause 19 (Figure 44), VDE0620 etc. It is applicable to the temperature rising of electronic accessories in working position.
Technical parameters:
Applied standard
IEC 60669-1
Applied clause
17
Working station
6
Testing current
0-125A
＜12V
Timer
0-9999s is adjustable, digital display
Power supply
220V,50HZ
● When the current exceeds the required value, the device stops working automatically. The range of the alarm is from 0 to the maximum current. The overcurrent time can be recorded automatically.
● When the temperature exceeds the required value, the device stops working automatically. The range of the alarm is from 0 to 150℃. The overtemperature time is recorded automatically.
Testing voltage
Temperature measurement table
0-150°digital display
Test object
Switches
