IEC 61032 Figure 14 Test Probe 31 for Testing Food Waste Disposal Units
Products Description
IEC 61032 Figure 14 Test Probe 31
Product Overview:
This probe conforms to the standard requirements of IEC 61032 test probe 31 figure 14, etc. This probe is intended to verify the protection against access to hazardous mechanical parts of the grinding system of food waste disposal units.
Probe Dimension:
Please refer to the relevant standards.
The test probe doesn’t have built-in force, if specific applied force required, the test probe should work together with a force gauge. At the end of our probe handle, there is a M6 thread hole to match the force gauge. Showing as following reference picture:
Probe diameter (mm)
Ф25±0.2
The length of the metal probe (mm)
80±0.2
Tip diameter of the cone (mm)
Ф60±0.2
End diameter of the cone (mm)
Ф110±0.2
Total length of probe and cone (mm)
150±0.2
Probe material
Stainless steel
Cone and handle material
Nylon
