IEC 61851-1 Stainless Steel IPXXD Test Rob Probe D With 3 N Force
Products Description
IEC 61851-1 Stainless Steel IPXXD Test Probe With Force
Product overview:
This rod probe is intended to verify the protection of persons against access to hazardous parts. It is also used to verify the protection against access with a wire.
Technical parameters:
Applicable standard
This probe conforms to the standard requirement of IEC61032 figure 4 test probe D, it is required by IEC 61851-1 clause 8 and 12.4, IEC 60335-1 clause 22.1, IEC60529 for IP4, IEC60065 and etc.
Customizable
It can be used for anti-electric shock test when equipped with alligator clip. Or used for enclosure protection test when open threaded hole of M6 at the end of the handle (connected with a pull and push force gauge). The probe whose model number with "T" is with built in force.
Model
SN2210-4
SN2210-4T (Optional)
Name
Test rod probe D
Test rod probe D with force
Test Wire Diameter
Ф1+0.05 0 (mm)
Ф1+0.05 0 (mm)
Stop Face Diameter
SФ35±0.2 (mm)
SФ35±0.2 (mm)
Handle Diameter
Ф10 (mm)
Ф10 (mm)
Test Wire Length
100±0.2 (mm)
100±0.2 (mm)
Handle Length
100 (mm)
----
Built-in Force
N/A
3N force
