IEC 62262 IK Code High Energy Pendulum Hammer Impact Test Apparatus
Products Description
IEC 62262 IK Code High Energy Pendulum Hammer Impact Test Apparatus
Product overview:
This High Energy Pendulum Hammer Impact Test Apparatus is a high-energy pendulum impact tester used for mechanical strength testing of household and similar electrical and electronic products and their accessories.
It conforms to standards:
IEC62262:2002 “Degrees of protection provided by enclosures for electrical equipment against external mechanical impacts (IK code)”
IEC60068-2-75:2014 “Environment testing for electric and electronic products Part2: Test methods -Test Eh: Hammer tests IDT”
IEC60598-1:2017 “Luminaries-Part1: General requirements and tests”
Design:
The high pendulum impact testing machine adopts a small structure and can move left and right. The impact height is heated by the lead screw, and the impact angle is 0-90° dangerous. In the point impact test, the potential energy of gravity is converted into kinetic energy to achieve the purpose of impact test on the sample.
Equivalent Mass
kg
Including but not limited to plug connection wall, hanging installation box, crimping cover, cover, lamp, etc.
It is mainly used for product impact test on the safety performance and performance of these products.
Technical Parameters
Striking Elements (Energy/J)
10J (2J, 5J,20J, 50J are optional)
1.7kg (500g, 5 kg,5 kg, 10kg are optional), please refer to following table 1
Striking Elements Material
Steel
Pendulum Tube
Length 1000㎜,outer diameter 15.9 mm, wall thickness 1.5 mm steel pipe
Impact Point
Up and down adjustable, stroke: 200-1200mm, the height is customizable
Height of Fall
0-500mm, scale display
Striking Element Fix and Release
Fixed by mechanical latch, released by spring device
