IEC 62368-1 Clause 5.4.1.5.3 Heating Chamber For Ball Pressure Test
Products Description
IEC 62368-1 Clause 5.4.1.5.3 Heating Chamber for Ball Pressure Test
Product information:
This heating chamber is required by IEC 62368-1:2018 clause 5.4.1.5.3, 5.4.1.10, Annex G.5.3.4, Annex G.13.6.2, Annex M.4.2, M.4.4.4, Annex. P.4, Annex T.8, IEC60950:2013 clause 2.10.8.2, clause 4.2.7, clause 4.5.5, clause 4.7.3.2, IEC 60695-10-3 etc.
Features:
1. The drying oven must be good grounded to ensure safe.
2. The drying oven should be placed in a room with good ventilation conditions and no
inflammable and explosive materials or toxic substances around it.
3. There is no explosion-proof device in the drying oven, don’t put inflammable and
explosive materials into it for drying.
4. Do not overcrowd the objects in the oven, especially around the temperature sensor, make room for hot air circulation.
5. Do not wipe the machine surface with acid or alkali or corrosive substances. The inside
and outside of the drying oven should be kept clean. If it is not used for a long time, cover
it correctly and put in a dry room. If any abnormality in use, please cut off the power supply
and contact us in time.
6.Be careful of scalding when using in high temperature.
Technical Parameters:
Applied Standard
IEC 62368-1
Clause
5.4.1.5.3, 5.4.1.10
Power supply
AC 220V, 50Hz
Temperature Range
RT+10°C ~300°C
Display Resolution
0.1°C
Temperature Fluctuation
±1°C
Power Rating
2600 W
Temperature Uniformity
±2.5°C
Display Method
LCD screen
Volume / Working Area Size (W* D* H)
50cm*60cm**75cm
Outer Dimensions (W* D* H)
70cm*71cm*110cm
Communication Interface
R485 interface on the right side of the device
Structure Type
Vertical
