IEC 62368-1 Clause Annex G.15 42Mpa Hydrostatic Pressure Test System
Products Description
IEC 62368-1 Clause Annex G.15 2.5Mpa Hydrostatic Pressure Test System
Product Information:
This hydraulic pressure test apparatus is designed and manufactured according to the standard requirements of IEC 62368-1 clause Annex G.15, IEC 60335-1 clause 22.47, IEC 60335-2-5 cl.22.101, IEC 60335-2-7 cl.22.101, IEC 60335-2-35 22.103, IEC 60335-2-24 cl.22.7, IEC 60335-2-15:22.7, etc. The test samples including valves, water heaters, treated fabrics, etc., this test apparatus is used to test the blasting performance test and water sealing performance test, water pressure resistance and static pressure of test samples.
The used environment:
Atmospheric pressure 80~106kpa; ambient temperature 5~40°C; relative humidity (20~80) %RH;
Use place: no rotation, no vibration, no electromagnetic interference, no dust, no explosive and no corrosive gas, with good heat dissipation.
Atmospheric pressure 80~106kpa; ambient temperature 5~40°C; relative humidity (20~80) %RH;
Use place: no rotation, no vibration, no electromagnetic interference, no dust, no explosive and no corrosive gas, with good heat dissipation
The test system adopts touch computer control and pneumatic water pressure booster pump and its pressure control device, which has the following advantages, such as printing data, displaying pressure curve, test pressure setting, constant pressure time, pressure rise rate, etc. The advanced technology and design and the beautiful appearance makes it easy to operate.
Applied Standard
IEC 62368-1
Applied Clause
Annex G.15
Power supply
Single phase AC 220V, 50Hz or match client's local power supply requirements
Operation interface
Touch type computer
Pressurized mode
Air pressure
Test pressure
0.5-42MPa
Hydraulic pressure control accuracy
5%FS
Water temperature
RT+5°C-60℃ controllable (accuracy ±1℃)
Water tank volume
30L
Pressure apply or hold time
0-999999s can be set
