IEC 62368-1 Clause Y.5.3 Water Spray Test Apparatus 5 Psi For Lamps Manual Control
Products Description
IEC 62368-1 Clause Y.5.3 Water Spray Test Apparatus 5 Psi For Lamps Manual Control
Product Information:
The Water Spray Test Apparatus conforms to the standard requirements of IEC 62368-1:2018 clause Y.5.3, UL1993 “Self-Ballasted Lamps and Lamp Adapters” clause 24, figure 24.1 and 24.2, UL60507-ENGL 1999 figure 38.1 and 38.2, ANSI Z21.10.3-2004, ANSI Z21.58 Figure 10/Figure 11, CSA4.3-2004, UL1598, UL153, UL154B, UL1703, UL8750, UL1741, UL514B, UL1278, UL1571, etc.
It is used to verify the protective performance of the enclosure for self-ballasted lamps and lamp adapters under UL water spray environment.
The water ingress testing equipment applies spray test to test sample by controlling the water supply pressure and the distance between the nozzle and sample.
The device consists of a 3 UL spray heads, 3 pressure gauges, 3 control valves and a water supply pipe rack.
Note: we only quote the test apparatus, the water supply should be offered by client.
Technical parameters:
Applied standard
IEC 62368-1
Applied clause
Y.5.3
Spray heads
3 pieces (or 4 pieces optional, with one lower nozzle)
Positions of spray heads
The positions of spray heads can be adjusted up or down through the water spray pipe rack
Lower nozzle angle (Optional)
45° up
Water pressure
At each head at approximately 34.5Kpa (5 psi), each spray head has a corresponding press gauge, total water flow pressure is 50-150Kpa
Distance between the device and the center nozzle
Approximately 1.4m (55 inches)
Rack
Material: high-grade aluminum profile with casters
