IEC60335-2-3 Electrical Appliance Testing Equipment Electric Irons Mechanical Strength 40mm 1000 Times Drop Test
Products Description
IEC60335-2-3 Electric Irons Mechanical Strength 40mm 1000 Times Drop Test Apparatus
IEC60335-2-3:2015 “Household and similar electrical appliances-Safety-Part 2-3:Particular requirements for electric irons” clause 21.101
IEC60335-2-2:2016 “Household and similar electrical appliances-Safety-Part 2-2:Particular requirements for vacuum cleaners and water-suction cleaning appliances,IDT” clause 15.101
IEC60335-2-17:2015 “Household and similar electrical appliances-Safety-Part 2-17:Particular requirements for blankets,pads and similar flexible heating appliances” clause 21.101
IEC60335-2-3:2015 clause 21.101
Standards & Clauses:
Samples and Restrictions:
Household and similar electrical appliances such as Electric iron, control device, power cleaning head for water absorbing cleaner.
Application:
It is used to check the mechanical strength of the electric iron under normal working conditions and rated power input, and also to test the drop resistance of the electric blanket control device.
Test Principle:
The iron (except for cordless irons) is suspended by its handle with the soleplate in the horizontal position through the cam mechanism driven by servo motor. It is dropped from a height of 40 mm onto a rigidly supported steel plate having a thickness of at least 15 mm and a mass of at least 15 kg. The test is carried out 1000 times at a rate not exceeding 20 drops per min. The test is conducted so that the iron rests on the steel plate for approximately 15% of the time.
Structure:
Chamber type structure, size: about 600 × 550 × 1200 (mm) W × H × D, weight: 80kg
Use Environment:
Power supply:AC220V±10%/50-60Hz, working temperature 0-40 ° C, humidity 30%-90%
Technical Parameters:
Model
SN1501
SN1701
Test Station
Single
Single
Electrical Control Method
Button control
Button control
Drive mode
The motor drives the cam mechanism to achieve a free drop action
The motor drives the cam mechanism to achieve a free drop action
Sample Clamping Method
Mounted to the drop mechanism by rope
Mounted to the drop mechanism by rope
Test Speed
≤20 drop/min
≤20 drop/min
Test Times
0~9999 times, can be preset
0~9999 times, can be preset
Drop Height
40 mm, with height positioning block
100 mm, with height positioning block
Support Plate
Thickness >15mm, mass > 15kg
Thickness >15mm, mass > 15kg
Load Power
Equipped with a universal socket, rated power input can be supplied to specimen
Equipped with a universal socket, rated power input can be supplied to specimen
Main Specimen
Electric iron, electric blanket control device
Power cleaning head for water suction cleaner
Standards Compliant
IEC60335-2-17:2015 clause 21.101IEC60335-2-2:2016clause 15.101
