Impact Strength Test Apparatus With 500mm Drop Height 1KG EN 71-1-1998 Clause 8.7
Products Description
Impact Strength Test Apparatus With 500mm Drop Height 1KG EN 71-1-1998 Clause 8.7
Product information:
The drop tester conforms to EN 71-1-1988 clause 4.14, EN 71-1-1998 clause 8.7. Adopts impact strength test methods to simulate a child playing or abusing toys or other items to determine the possibility of injury.
Technical Parameters:
Steel with chrome-plated surface
Operation steps:
Please refer to the relevant standards.
Take EN 71-1-1988 clause 4.14 as an example:
Place the toy on a plane, horizontal steel surface and drop a metallic mass of 1 kg, distributed over an area of 50 cm², through a distance of 100mm on to the toy.
Examine whether the casing has broken.
Horizontal steel surface size
215 (length) x280 (width)
Adjustable drop height
0-500mm
Impact metallic mass
1kg ± 0.02kg weight, diameter:80mm ± 2mm
Impact distributed area
Distributed over an area of 50cm²
Frame material
