UL94 Horizontal And Vertical Burning Test Apparatus 50W 500W Double Power Switching
Products Description
UL94 Horizontal And Vertical Burning Test Apparatus 50W 500W Double Power Switching
Standard: IEC60695-11-10, IEC60695-11-20, UL94, IEC60695-11-2, IEC60695-11-3, IEC60695-11-4.
Application:It is required by IEC 62368-1:2018 Annex S, IEC 60950:2013 clause 4.7.3, IEC60065:2014 clause 14.1, 20.2.1, 20.2.4, Annex G, IEC60335-1 clause 30, etc. It simulates the influence of early-stage flame when there is a fire around the electric and electronic products, so that to judge the igniting danger degree. It is mainly used in plastic and other non-metallic material sample, solid material. It is also applicable in the Horizontal, vertical flammability test of the relative combustion characteristic of foam plastics whose density is no-less than 250kg/m according to ISO845 test method.
Test sample:It is also applicable in the Horizontal, vertical flammability test of the relative combustion characteristic of foam plastics whose density is no-less than 250kg/m according to ISO845 test method.
Feature: This series of products adopt integral type inlet ignition system. The combustion time delays 0.1S thus to make sure the sufficient time of gas burning. They are with matte black background, multi-functional flame measure gauge, stainless steel of box full, large observation window, imported digital indicator of high precision, nice appearance. And they gather a number of advantages of similar products home and abroad.
Technical Parameters:
IEC60695-11-10/IEC60695-11-20, UL94, etc.
50W:10mm;
50W: 0°,45°;
Product Information:
Working voltage
220V/50Hz
Power/grade
50W and 500W double power switching
Control operation mode
PLC control, 7-inch color touch screen operation, with infrared remote controller
Blast burner standard
inner diameter:Φ9.5±0.3mm,length:100mm,made of brass
Gas pressure
0.1MPa
Gas flow
50W:105±5ml/min or 18±1mm;500W:965±30ml/min or 117±3 mm,flow meter adjustment
U type pressure gauge back pressure water column height
500W:125±5 mm
Test angle
500W: 20°
Burning time
0-9999X0.1S Can be preset
Burning times
0-9999 times,Can be preset
Residual flame/Residual glow
0-9999X0.1S Can be displayed
Test flame calibration
Temperature measuring copper head:50W:Ф5.5mm±0.01mm,weight before drilling 1.76 ± 0 .01 g；500W:Ф9mm±0.01mm,weight before drilling 10 ± 0 .05g
Thermocouple: The American original Omega φ0.5 armour nickel-chromium/nickel aluminum wire K-Thermocouple, temperature resistance 1100°
Distance between the bunsen burner port to temperature measuring copper block:50W: 10±1 mm; 500W: 55±1 mm
Flame height:50W: 20±2mm(there is no internal and external flame); 500W: Inner flame:40±2mm,Outer flame:125±10mm
Temperature rise time from100±2°to 700°±3°50W: 44±2S; 500W: 54±2S
Lighting
Equip with lighting in the test chamber, with control
Test chamber and dimension
> 0.75 cube, black inwall, with exhaust fan, dimension:1100*550*1200mm, 140kg
