Windproof Chamber For Lamps Product Temperature Measurement Customizable Size IEC 60598-1
Products Description
Windproof Chamber For Lamps Product Temperature Measurement Customizable Size IEC 60598-1
Product overview:
This windproof chamber is designed according to standard IEC 60598-1:2017 Clause 12.4.1 and Annex D and etc. Applied to provide standard environment condition for lamps product temperature measurement.
The bottom surface is solid wood panels, the other sides are double-layer metal mesh plates, mesh plates spacing is 150mm, ventilation rate of about 40%; all the plates are black matt painted.
Technical parameters:
24 channels, measuring range: up to 260°C, measuring accuracy: ±(0.05% rdg. +0.5℃), display resolution: 0.01°C
Aluminum profile structure (four stations)
Main configuration:
Windshield installation requirements:
External requirements:
Internal sample installation requirements:
Outer size
2100 x 2100 x 2168 mm (L x D x H)
Inner size
1800 x 1800 x 2000mm (L x D x H)
Metal mesh plates space
150mm
Door structure
Single, double layer (outward open), 900mm x 1900mm (W*H)
Aperture of screen
ф2mm
Ventilation rate
Approx. 40.5%
Surface coating
black matt paint
Floor plate size
2100mm x 2100mm x 18mm (L x D x Thickness)
Temperature measuring device
Sample placement rack
Temperature sensing copper sheet + 3 meters thermocouple wire
25 NOS
No.:
Name
Spec.
QTY
1
Outer enclosure
L2100mmXD2100mmXH2168mm
1 Set
2
Inner enclosure
L1800mmXD1800mmXH2000mm
1 Set
3
Swing door
W 900mmX H 1900mm (single fan, double layer)
1 PC
4
Floor
L2100mmXD2100mmXH18mm
1 Set
5
Sample rack
Aluminum profile structure (four stations)
1 Set
6
Temperature sensing copper sheet + 3 meters thermocouple wire
25 Nos
7
Temperature measuring device
24 channels
1 Set
There is at least 300mm clearance around the top and sides of the draft shield.
The location of the windshield should be as far away as possible from the air flow and prevent sudden changes in air temperature and radiant heat of the light source.
Ambient temperature: about 25 ℃.
The gap between the inner surface of the draft shield and any part of the lamp should be at least 200mm.
When multiple lamps are tested at the same time, attention should be paid to use light barriers to prevent the radiant heat between lamps from affecting each other.
Different lamps are tested in the same state as they are in actual use as far as possible. This equipment has provided a variety of baffles that can be combined to facilitate various combinations.
